Emission Standard |
China Ⅳ |
China Ⅳ |
China Ⅳ |
Basic parameters ●Available ○N/A |
Engine type |
Inline 4 cylinder |
Inline 4 cylinder |
Inline 4 cylinder |
Max. Power/rpm(kW/rpm) |
62/13500 |
62/13500 |
62/13500 |
Max. Torque/rpm(N·m/rpm) |
46/11500 |
46/11500 |
46/11500 |
Max. Speed(km/h) |
235 |
235 |
235 |
Fuel consumption(L/100km) |
|
|
|
Length x Width x Height(mm) |
2005*705*1125 |
2005*705*1125 |
2005*705*1125 |
Seat height(mm) |
800 |
800 |
800 |
Wheel base(mm) |
1395 |
1395 |
1395 |
Curb weight(kg) |
168 |
168 |
175 |
Net weight(kg) |
158 |
158 |
165 |
Fuel Capacity(L) |
15 |
15 |
15 |
Steering angle(°) |
25 |
25 |
25 |
Rake Angle((°) |
24.5 |
24.5 |
24.5 |
Trail (mm) |
98 |
98 |
98 |
Colors |
Pearl White,Metallic Black,Neon Green,Hot Pink |
Pearl White,Metallic Black,Neon Green,Hot Pink |
Pearl White,Metallic Black,Neon Green,Hot Pink |
Optional color of rim available for |
Neon Green,Hot Pink |
Neon Green,Hot Pink |
Neon Green,Hot Pink |
Powertrain ●Available ○N/A |
Engine type |
ZX459MR |
ZX459MR |
ZX459MR |
Displacement(cc) |
470 |
470 |
470 |
Aspiration Type |
Naturally Aspirated |
Naturally Aspirated |
Naturally Aspirated |
Engine Configuration |
Inline
|
Inline
|
Inline
|
Number of Cylinders |
4-Cylinder |
4-Cylinder |
4-Cylinder |
Valvetrain |
DOHC (Dual Overhead Camshaft), 4 Valves per Cylinder |
DOHC (Dual Overhead Camshaft), 4 Valves per Cylinder |
DOHC (Dual Overhead Camshaft), 4 Valves per Cylinder |
Bore × Stroke (mm) |
59*43 |
59*43 |
59*43 |
Engine Cycle |
4-Stroke |
4-Stroke |
4-Stroke |
Compression Ratio |
12.9:1 |
12.9:1 |
12.9:1 |
Cooling System |
Liquid-Cooled |
Liquid-Cooled |
Liquid-Cooled |
Max. Power (Ps) |
85 |
85 |
85 |
Max. Power (kW) |
62 |
62 |
62 |
Max. power rpm(rpm) |
13500 |
13500 |
13500 |
Max. torque(N·m) |
46 |
46 |
46 |
Max. torque rpm(rpm) |
11500 |
11500 |
11500 |
Fuel type |
Gasoline(95 RON) |
Gasoline(95 RON) |
Gasoline(95 RON) |
Fuel delivery |
BOSCH EFI |
BOSCH EFI |
BOSCH EFI |
Emission Standard |
China Ⅳ |
China Ⅳ |
China Ⅳ |
Muffler |
SUS304 impedance composite silencer |
SUS304 impedance composite silencer |
SUS304 impedance composite silencer |
Air filter |
Ram air intake |
Ram air intake |
Ram air intake |
Drivetrain ●Available ○N/A
|
Transmission |
6-speed international
|
6-speed international
|
6-speed international
|
Clutch type |
Wet multi-plate slipper clutch |
Wet multi-plate slipper clutch |
Wet multi-plate slipper clutch |
Final drive |
Chain |
Chain |
Chain |
Slipper clutch |
● |
● |
● |
Wheel & Brake ●Available ○N/A |
Tire Brand |
CST S5 |
CST R01 |
Helios RS21 |
Front wheel size |
120/70 ZR17 |
120/70 ZR17 |
120/70 ZR17 |
Rear wheel size |
180/55 ZR17 |
180/55 ZR17 |
180/55 ZR17 |
Tire type |
Tubeless |
Tubeless |
Tubeless |
Rim |
Aluminum alloy cast front MT3.5*17 rear MT5.5*17 |
Aluminum alloy cast front MT3.5*17 rear MT5.5*17 |
Aluminum alloy cast front MT3.5*17 rear MT5.5*17 |
Front caliper |
4-Piston opposed caliper (TAISKO) |
4-Piston opposed caliper (TAISKO) |
2-Piston opposed caliper (TAISKO) |
Front disc |
300mm dual floating disc |
300mm dual floating disc |
300mm dual fixed disc |
Front brake lever |
Direct push master cylinder |
Direct push master cylinder |
Side push master cylinder |
Rear caliper |
2-piston opposed caliper(TAISKO) |
1-piston floating caliper(TAISKO) |
1-piston floating caliper(TAISKO) |
Rear disc |
220mm single disc |
220mm single disc |
220mm single disc |
Safety ●Available ○N/A |
ABS |
Cornering ABS |
Cornering ABS |
Cornering ABS |
ABS Disable |
●Front/Rear |
●Front/Rear |
●Front/Rear |
Tire pressure monitor |
- |
- |
- |
TCS |
● |
● |
● |
Steering damper |
● |
● |
- |
Tip-over sensor |
● |
● |
● |
Side stand safety cutoff |
● |
● |
- |
Auxiliary/control●Available ○N/A |
Riding modes |
Sport/Street/Beginner/ 2 customized |
Sport/Street/Beginner/ 2 customized |
Sport/Street/Beginner |
Throttle |
Double-cable throttle |
Double-cable throttle |
Double-cable throttle |
Quick shifter |
●Single direction |
●Single direction |
- |
Electronic suspension |
- |
- |
- |
Cruise control |
- |
- |
- |
Engine start-stop system |
- |
- |
- |
Pulse ignition system |
- |
- |
- |
Launch control |
● |
● |
● |
Multimedia & Comfort●Available ○N/A |
Dashboard |
TFT |
TFT |
TFT |
Mobile connectivity(bluetooth/Wi-Fi,etc.) |
● |
● |
● |
Navigation screen mirroring |
● |
● |
● |
Gear indicator |
● |
● |
● |
Fuel consumption display |
● |
● |
● |
T-BOX |
● |
● |
● |
USB charging port |
● |
● |
- |
Kyless ignition |
- |
- |
- |
Lighting ●Available ○N/A |
Headlight |
LED |
LED |
LED |
Taillight
|
LED |
LED |
LED |
Turn signals |
LED |
LED |
LED |
Auxiliary lights |
- |
- |
- |
Hazard lights(double flash) |
● |
● |
● |
Automative headlight |
● |
● |
● |
Daytime running lights (DRL) |
- |
- |
- |
Chassic & suspension ●Available ○N/A |
Frame type |
One-piece steel tubula braided frame |
One-piece steel tubula braided frame |
One-piece steel tubula braided frame |
Rear swingarm |
Single-sided swing arm(aluminum alloy) |
Double swing arm(aluminum alloy) |
Double swing arm(aluminum alloy(high strength steel) |
Front suspension |
Inverted φ 41, fully adjustable preload and damping |
Inverted φ 41, adjustable preload |
Inverted φ 41, unadjustable
|
Rear suspension |
Central monoshock, fully adjustable preload and damping |
Central monoshock, adjustable preload and rebound damping |
Central monoshock, adjustable preload |
Batteries |
4AH |
4AH |
4AH |
Seat |
Split type |
Split type |
Split type |
